Name: SMD3535 P5 P6 Outdoor LED Display 6mm Pixel Video Wall
Brand: SHENZHEN KAILITE OPTOELECTRONIC TECHNOLOGY CO., LTD
SKU: P6屋外用LEDディスプレイ
Price: 400.00 USD
Availability: InStock

ホーム製品屋外広告 Led 表示

SMD3535 P5 P6 Outdoor LED Display 6mm Pixel Video Wall

商品の詳細:

起源の場所:	中国広州
ブランド名:	kailite p5 P6 outdoor led display
モデル番号:	P6屋外用LEDディスプレイ

お支払配送条件:

最小注文数量:	3

連絡先

詳細製品概要

ピクセルピッチ:	6mm	モジュールサイズ:	192mm*192mm
LEDランプ:	SMD3535	運転モード:	一定の運転1/8スキャン
モジュール力:	35W	最大消費電力:	900W
物理密度:	27777dots/平方メートル	ピクセル構成:	1R1G1B
モジュール解像度:	32*32	推奨する視距離:	6-70m
表示角度:	H: 120° V:120°	平均消費電力:	460W
キャビネットサイズ:	960*960mm	キャビネットの重量:	35kg/パネル
動作温度:	-30℃~+45℃
ハイライト:	SMD3535 outdoor LED display , P5 P6 LED video wall , 6mm pixel outdoor display

Shenzhen Factory RGB Fixed Installation for SMD3535 P5 P6 Outdoor LED Display

Product Specifications

Attribute	Value
Application	Outdoor
Use	Advertising, retail stores, shopping malls, exhibitions, wayfinding, airports, subways, restaurants, hotels, education
Pixels	6MM
Color	Full color
Module size	192mm*192mm
LED lamp	SMD3535
Driving mode	Constant Driving 1/8 Scan
Module power	35w
Max power consumption	900w
Specification	Video Wall

Product Overview

LED technology has revolutionized visual displays worldwide. As a premier application of this technology, our LED screens deliver exceptional visual experiences across diverse environments, transforming spaces with vibrant colors and dynamic content.

SHENZHEN KAILITE OPTOELECTRONIC CO.,LTD specializes in manufacturing high-quality LED displays. We offer customized solutions with competitive pricing and guaranteed quality, ready to meet your specific requirements.

Key Features

Customized solutions tailored to your specific needs
Direct factory pricing with quality assurance
Energy-efficient and environmentally friendly design
Simple installation and easy maintenance
Enhanced heat dissipation with specially designed vent fans

Technical Specifications Comparison

Parameter	P5 Model	P6 Model
Pixel Pitch	5mm	6mm
Use Environment	Outdoor	Outdoor
Module Size	160*160mm	192*192mm
Pixel Density	40,000 dots/m²	27,777 dots/m²
LED Chip	SMD3535	SMD3535
Module Resolution	32*32	32*32
Module Power	30w	35w
Viewing Distance	5-45m	6-70m
Viewing Angle	H:120° V:120°	H:120° V:120°
Max Power Consumption	850w	900w
Ingress Protection	Front:IP67; Back:IP65	Front:IP67; Back:IP65
Lifetime	>100,000 Hours	>100,000 Hours
